| Specification |
| Load cell Rating | 60/100/150/200/300kg |
| Accuracy | C3 |
| Sensitivity | 2.0±0.15mv/v |
| Zero balance | ±2% F. S |
| Nonlinearity | ±0.02% F. S |
| Hysteresis | ±0.02% F. S |
| Repeatability | ±0.02% F. S |
| Creep(30min) | ±0.02% F. S |
| Temperature influence on Zero | ±0.017% F. S / 10℃ |
| Temperature influence on Output | ±0.017% F. S / 10℃ |
| Input impedance (W) | 405±5 |
| Output impedance (W) | 350±3 |
| Insulation impedance (W) | ≥5000M W (50VDC) |
| Temperature compensation range | -10℃ ~ +40℃ |
| Operating temperature range | -30℃ ~ +70℃ |
| Safe overload capacity | 150% F. S |
| Ultimate overload capacity | 200% F. S |
| Recommended excitation voltage | 10 ~ 15V |
| Maximum excitation voltage | 18V |
| Cable | Φ5.6x2m |
| Cable connection | Input: Red (+) Black (-) |
| Output: Green (+) White (-) |
